Hawk Gladiator series User Manual

5
Dimensions
Gladiator Conductivity Switch Series
RemoteAmplier
14 mm (0.6”)
74 mm (2.9”)
78 mm (3.1”)
107 mm (4.2”)
111.5 mm (4.4”)
4 mm (0.2”)
50 mm (2”)
131.5 mm (5.2”)
7.5 mm (0.3”)
192.5 mm (7.6”)
141.5 mm (5.6”)
190 mm (7.5”)
182.5 mm (7.2”)
147 mm (5.8”)
167.5 mm (6.6”)
147 mm (5.8”)
30.7 mm (1.2”)
158 mm (6.2”)
108 mm (4.3”)
190 mm (7.5”)
174 mm (6.9”)
192.5 mm (7.6”)
182.5 mm (7.2”)
30.0
20
.
2
33.029.029.033.0
1
6
.
2
A B
C
Flange Dimensions - 50mm (2”)
A B C
ANSI (Class 150) 120.7 4.75” 152.4 6” 19.1 0.75”
DIN (PN40) 125 4.9” 165 6.5” 18 0.7”
JIS (10K) 120 4.7” 155 6.1” 19 0.75”
Optional Flange
Standard probe lengths
(L1 or L2):
• 30 cm (11.8”)
• 50 cm (19.7”)
• 100 cm (39.4”)
Single Probe Two Probe
Single Switch Points
Bare probe 50mm (2”)
85mm (3.3”)
probe length = L1
M20 cable gland
or 3/4” NPT adaptor
on smart type.
Window for
viewing status
LEDs
Mounting
thread
90mm (3.5”)
50mm (2”)
5mm (0.2”)
85mm (3.3”)
Window for
viewing status
LEDs
Optional
Flange
90mm (3.5”)
50mm (2”)
2 x M20
cable glands
or 3/4” NPT adaptors
on remote type.
8mm (0.3”)
teflon isolated probe for build-up protection
Bare probe 50mm (2”)
probe length = L1 = L2
teflon isolated probe for build-up protection
85mm (3.3”)
Window for
viewing status
LEDs
90mm (3.5”)
50mm (2”)
probe length L2
probe length L1
10mm (0.3”)
teflon isolated probe for build-up protection
Mounting
thread, 1.5” NPT
or BSP only
Mounting
thread, 1.5” NPT
or BSP only
Bare probe 50mm (2”)
85mm (3.3”)
probe length = L1
M20 cable gland
or 3/4” NPT adaptor
on smart type.
Window for
viewing status
LEDs
Mounting
thread
90mm (3.5”)
50mm (2”)
5mm (0.2”)
85mm (3.3”)
Window for
viewing status
LEDs
Optional
Flange
90mm (3.5”)
50mm (2”)
2 x M20
cable glands
or 3/4” NPT adaptors
on remote type.
8mm (0.3”)
teflon isolated probe for build-up protection
Bare probe 50mm (2”)
probe length = L1 = L2
teflon isolated probe for build-up protection
85mm (3.3”)
Window for
viewing status
LEDs
90mm (3.5”)
50mm (2”)
probe length L2
probe length L1
10mm (0.3”)
teflon isolated probe for build-up protection
Mounting
thread, 1.5” NPT
or BSP only
Mounting
thread, 1.5” NPT
or BSP only
Two Probe
Dual Switch Points
