Part Numbering
Gladiator Conductivity Switch Series
25
Smart Probe Version
CS3100 Gladiator Conductivity Switch - Smart Probe
Power Supply
B 12-30VDC
U 12-30VDC and 90-260VAC
Output Options
S Switch only, 1 level relay, Modbus
Housing
S Standard Powder Coated, Diecast with glass lid
C Corrosion Resistant, Stainless Steel Housing
Type of Electrodes
S Single Point 1 Electrode Type for Metallic tanks
D Dual Point 2 Electrode Type for Metallic tanks
N Single Point 2 Electrode Type for Non-Metallic tanks (L1 must = L2)
Mounting
TN10 1” NPT Thread - Size only available for 1 electrode type
TB10 1” BSP Thread - Size only available for 1 electrode type
TN15 1.5” NPT Thread
TB15 1.5” BSP Thread
FA2 2” Flange ANSI (Class 150)
FD2 2” Flange DIN 50 (PN 40)
Approval Standard
X Not Required
A22 ATEX Grp II Cat 3 GD T85°C IP67 Tamb -40°C to 70°C
L1 Probe Length (Active Probe)
P30 300 mm (11.8”)
P50 500 mm (19.7”)
P100 1000 mm (39.4”)
L2. Probe Length (Reference Probe - equal to or longer than L1)
X Not required for 1 electrode type
P30 300 mm (11.8”)
P50 500 mm (19.7”)
P100 1000 mm (39.4”)
CS3100 B S S S TN10 X P30 X Single Point Switch - Metallic Tank
CS3100 B S S D TN15 X P30 P50 Dual Point Switch - Metallic Tank
CS3100 B S S N TN15 X P30 P30 Single Point Switch - Non-Metallic Tank
Non-standard probe lengths available. Contact Factory.
