Dimensions
Gladiator Conductivity Switch Series
Mounting
Probes can be mounted from above or from the side.
Use a protection plate for side mounting where the probe may be subject to impact damage.
Install the Probe far enough away from the vessel wall to prevent the probe from coming into contact with the
wall, and prevent conductive build-up from bridging the probe to the wall over time.
Correct
Correct (non-preferred
low level mounting)
Incorrect
1
2
Correct
Correct
If necessary, mount a
protection plate to
prevent direct impact.
1
Housing can be rotated
within 200º after the
mounting thread is
tightened, to allow cable
entries to face downwards
or allow optimal cable
clearance.
30-45º
Possible
product
build-up
Possible conductive
build-up
Correct
Correct
Incorrect
Incorrect
Incorrect
2
