Rate 1 ：（0.10-1800.00）ml/h
VTBI 2 : (0.10-9999.99）ml
Rate 2 ：（0.10-1800.00）ml/h
8.1.5 Purge
Press Bolus key until the air bubble in infusion tube is totally exhausted.. The volume generated by
“purge” is not calculated in accumulated volume.
Note: “purge” only use when machine is in non-infusion status, and infusion tube is not
connected to patients.
8.1.6 Start infusion
Check if parameters are correct and then push “Start” key to start infusion. Only Bolus and Stop key
are available during the infusion except alarm. Under infusion status, the word “Running”will be displayed
at bottom of screen; the indicator light will flash in green.
8.1.7 Bolus (Fast infusion)
There are two methods to purge. They are manual bolus and auto bolus. Please follow by the followi
ng procedures:
1) Manual bolus: During infusion process, press bolus key and hold on. The pump will p
urge at preset bolus rate. It will return to previous infusion rate after releasing your finger.
2)Auto bolus: After setting bolus rate, it will purge at bolus rate by single clicking bolus key.
Attention: Different syringes have different bolus rate. Bolus rate can be setting on the system menu,
please refer to 8.4.6 in user manual.
8.1.8 Stop infusion
Press Stop key to stop the infusion. In this case, the indicator light will be off; the interface will show
volume infused and adjustable parameters.
(1) User could reset the parameters in this interface and press START key to continue infusion.
(2) To complete the infusion, the user could select “End infusion” then press OK key. It will return to
infusion mode setting interface.
8.1.9 Infusion complete
