Hayter R324T User Manual

DECALS
Decal - Control Panel Part No: 994910 (A)
Location: Control Panel.
a) Ignition Switch f) Horn
b) Engine Speed - Slow g) Cutters - Lift
c) Engine Speed - Fast h) Cutters - Hold
d) Parking Brake - Engage i) Cutters - Drop/Float
e) Parking Brake - Disengage j) Hour Meter
Decal - Inclines Part No: 111-0955 (A)
Location: Centre Platform.
a) Warning - Travel slowly when turning and on slopes
b) Warning - Maximum Slope
c) Warning - Seat belt must be worn only with a ROPS in
the vertical position.
d) Caution
e) Read operators manual
f) Stop engine/Remove ignition key before servicing or
maintenance
g) Beware of flying objects
h) Keep bystanders clear
Decal - Danger Latch Part No: 70-13-077
Location: LH / RH / Centre Arms
a) Caution
b) Stop engine/Remove ignition key before releasing or
operating safety latches
Decal - Diesel Part No: 70-13-078
Location: Fuel Tank
Diesel fuel only
Decal - Transmission Oil Part No: 70-13-071
Location: Oil Filler Bracket mounted behind Fuel Tank.
a) Transmission oil
b) Read and understand the operators manual.
