INTRODUCTION
The Hayter R324T High Output Rotary is a diesel engine powered self-propelled machine with hydraulic
systems for ground drive, cutterdeck drives and steering.
The machine can be operated in either two wheel or four wheel drive and a differential lock function
may be selected in four wheel drive.
The Hayter R324T High Output Rotary is a precision built machine designed solely for cutting grass and
similar low lying ground vegetation within the limitations stated in this manual. Do not use the R324T
in any other way other than its intended use as stated above. Compliance with and strict adherence to the
conditions of operation, service and repair as specified in this Operators Manual also constitute essen-
tial elements of the intended use. The way in which this machine is operated and maintained will have
a profound effect on its performance and reliability.
This manual contains advice on the Hayter R324T High Output Rotary which should be operated,
serviced and repaired only by persons who are familiar with its particular characteristics and who are
acquainted with the relevant safety procedures.
The safety precautions listed here in and all other generally recognised regulations on safety and all road
traffic regulations must be observed at all times.
Any arbitrary modifications carried out to this machine may relieve Hayter Limited of liability for any
resulting damage or injury.
In the pursuit of continuous product development Hayter Limited reserve the right to alter specifications
without notice.
Cutterdecks: The Hayter R324T High Output Rotary is fitted with the following cutterdeck configuration:
Optional Extras:
Beacon Kit - Amber flashing warning light.
Lighting Kit - Complies with EC traffic regulations.
R.O.P.S. Cab - Full weather protection and roll - over protection.
Note: With a R.O.P.S Cab fitted stability angle will decrease, due to the higher centre of gravity of
the machine.
Left and Right: Throughout this manual the terms 'Left' and 'Right' refer to the machine when
looking in the direction of forward travel.
Cutterdeck
Number of
cutter blades
Cutter Blade
length
Centre
L.H.
R.H.
560mm (22")
560mm (22")
560mm (22")
3
2
2
Direction of Rotation
Viewed on Motor Shaft End
RH Blade - Clockwise
Middle Blade - Anti-clockwise
LH Blade - Anti-clockwise
Clockwise
Anti-clockwise
1.17
1.17
INTRODUCTION
