1.23
1.23
SPECIFICATIONS
Wheel Base:
Working Width:
Cutting Width:
Transport Width:
Overall Length:
Transport Height:
Working Weight:
WEIGHT AND DIMENSIONS
RECOMMENDED LUBRICANTS AND HYDRAULIC FLUIDS
Grease Points: A good quality medium grease.
Engine: Refer - ENGINE OPERATORS MANUAL.
Hydraulic System:
Should you be in any doubt please contact your Hayter dealer. Using incorrect grades will cause
premature wear of hydraulic components and invalidate warranty.
1610 mm (63.4”).
3610 mm (142.1") - At 100mm (4") height of cut.
3500 mm (137.8") - At 100mm (4") height of cut.
1774 mm (69.8") - At 50mm (2") height of cut.
3470 mm (136.6").
1750 mm (68.9") with R.O.P.S folded.
2404 mm (94.6") with R.O.P.S in its vertical operating position.
Including 2 post R.O.P.S, cutterdecks and full tank of fuel.
It excludes the operator and any other options.
1869 kg (4120 Ib).
Ambient Temperature Range
0 - 30 C (32 - 86 F)
I S O viscosity grade
46 hydraulic oil.
O
O
15 - 40 C (59 - 104 F)
I S O viscosity grade
68 hydraulic oil.
O
O
O
