SPECIFICA
TIONS
CUTTERDECKS
Cutterdeck Width:
Cutting Width:
Cutterblade Length:
Cutterblade Speed:
Cutterblade Overlap:
Height of Cut:
Number
of Cutter
Blades:
Configuration:
Breakback Mechanism:
T
yres:
Centre Cutterdeck
1675 mm
1600 mm.
558 mm.
2400 rpm approx.
63 mm
26 - 127 mm.
3
Semi-floating
-
Puncture Preventative
Left/Right Cutterdecks
1
150 mm
1090 mm.
558 mm.
2400 rpm approx.
40mm
26 - 127 mm.
2
Fully floating
Gas spring
Puncture Preventative
23
25
Table of Contents
Rotary Mower
1
Table of Contents
4
Safety Precautions. 1.6
10
Maintenance and Storage
10
Decals. 1.11
11
Decals Continued
12
Ec Conformity Information. 1.15
15
Noise Levels / Vibration Levels
15
EC Declaration of Conformity
16
Introduction
17
Specifications. 1.18
18
Engine
18
Transmission System
19
Cutterdeck Drive System
19
Cutterdeck Lift System and Steering
20
Hydraulic System
20
Vehicle Specifications
21
Operator Controls
22
Instrumentation
22
Weight and Dimensions
23
Recommended Lubricants and Hydraulic Fluids
23
Cutterdecks
24
Operating the Mower. 1.25
25
Safety Notice
25
Operator Presence Controls
25
Identification of Controls
26
Braking System
27
Throttle Control
27
Travel
27
Work/Transport Modes
28
Transport Latches
28
Differential Lock
29
Travel Control Pedals
29
Forward Travel Speed Backstop Lever
30
Operator Platform Latching Mechanism
30
Adjustable Steering Column
31
Folding the R.O.P.S 1.32
32
Operator Seat
34
Warning Systems
35
Audible Warning Horn
35
Fuel Level Gauge
36
Hourmeter
36
Ignition Key
36
Engine Pre-Heat Indicator Light
36
Transmission Neutral Indicator Light
37
Cutterdeck Drive Switch Indicator Light
37
Parking Brake Indicator Light
37
Hydraulic Return Filter Indicator Light
37
Hydraulic Transmission Filter Indicator Light
37
Transmission System 'Work' Mode Indicator Light
37
Cutterdeck Position Control
38
Cutterdeck Drive Engagement
38
Starting the Engine
39
Stopping the Engine
40
General Operating Hints
40
Cutterdeck Gerneral Information
41
Maintenance
44
Engine
45
Running in Period
45
Running in Period - at First 50 Hours. 1.45
46
Daily and before Use. 1.47
47
Every 50 Hours
51
Every 250 Hours
52
Every 500 Hours
53
Cutterdecks
56
Cutterblade Removal
57
Cutterblades
57
Raising the Mower off the Ground
59
Towing the Mower. 1.60
60
Grass Cutting Faults. 1.62
63
Troubleshooting
64
Trouble Shooting. 1.64
64
Electrical Circuit Diagram. 1.71
71
Transmission/Brake Hydraulic Circuit. 1.75
75
Hydraulic Circuit Diagram. 1.77
77
Warranty
79
Notes
80
Customer Information
81
