1.20
1.20
SPECIFICATIONS
CUTTERDECK LIFT SYSTEM AND STEERING
Drive Type:
Pump:
Delivery Rate:
Steering:
Cutterdeck Lift Control:
Relief Valve Setting:
HYDRAULIC SYSTEM
Hydraulic Oil Type:
Capacity:
Cooling:
Suction Line Filtration:
Return line Filtration:
Transmission Filtration:
Max Operating Temp:
Cleanliness Level:
Hydraulic.
Hydraulic gear pump with integral relief valve.
11 Litres per minute (2.9 Uk gallons per minute).
Power beyond hydrostatic steering valve with priority flow to
steering and auxiliary flow to cutterdeck lift system. Manual
emergency steering.
Mechanical-hydraulic.
120 bar (1523 psi) on pump.
Refer - RECOMMENDED LUBRICANTS
AND HYDRAULIC FLUIDS.
77 Litres (17 gallons).
Combined aluminium oil and water cooler.
125 micron no bypass mesh filter.
10 micron with 2 bar (29 psi) bypass check valve.
10 micron no bypass pressure filter.
95
0
C (203
o
F)
150 Code 18/13 or better (150 4406)
1300 - Particles/ml<15μ
40 - 80 Particles/ml>15μ
To Next Page
