1.72
1.72
ELECTRICAL CIRCUIT DIAGRAM
1. Switch - Parking Brake Interlock. 950865
2. Glow Plug Timer. 15694-65992
3. Light - Parking Brake. 924601/950858
4. Light - Glow Plugs. 924601/950857
5. Light - Neutral. 924601/950862
6. Light - Cutterdeck Drive Off. 924601/950861
7. Light - Return Filter. 924601/950866
8. Light - Pressure Filter. 924601/950863
9. Light - Battery Warning. 924601/924605
10. Light - Engine Oil Pressure. 924601/924606
11. Light - Engine Coolant Temperature. 924601/924602
12. Light - Hydraulic Oil Temperature. 924601/924603
13. Diodes - Overheat - Audible Warning. 950868 Supplied with Loom
14. Switch - Beacon (supplied with beacon kit). 924608
15. Switch - Work/Transport Mode. 924607
16. Solenoid - L/H Cutterdeck Drive. 70-06-246
17. Solenoid - Centre Cutterdeck Drive. 70-06-246
18. Solenoid - R/H Cutterdeck Drive. 70-06-246
19. Switch - R/H Deck Interlock. 994865
20. Switch - Cutterdeck Drive 511.106. 924607 (Lens 950856)
21. Fusebox. 70-09-096
1. 10A Cutter Drive & Lift Configuration 70-09-026
2. 10A Transmission & Horn 70-09-026
3. 3A Instruments 70-09-024
4. Blank (Beacon) -
5. Blank (Cab Wipers) or (Air Suspension Seat) -
6. Blank (Lighting Kit) -
7. Blank (Lighting Kit) -
8. 30A Engine Start (Fuel Solenoid) 70-09-027
22. Switch - Ignition. 74-09-009
23. Switch - Horn. 924618
24. Fuse - Engine Glow Plugs 60A. 950926 Supplied with Loom
25. Relay - Overheat Audible Warning. 70-09-148 Supplied with Loom
26. Diode - Seat Switch. 950868 Supplied with Loom
27. Relay - Glow Plugs. 924625 Supplied with Loom
28. Timer - Operator Presence Interlock. 70-01-512
29. Diode - Parking Brake. 950868 Supplied with Loom
30. Relay - Seat Switch. 70-09-148 Supplied with Loom
31. Temperature Gauge (supplied with temp kit). -
32. -
33. Connectors for Lighting Kit. - Supplied with Loom
34. Horn. 70-09-108
35. Switch - Operator Seat. 953819
36. Solenoid - Differential Lock. 910627
37. Switch - Differential Lock. 994860
38. Switch - Pressure Filter. -
39. Switch - Hydraulic Oil Temperature. 940852
40. Connection for Beacon Kit. - Supplied with Loom
41. Switch - Neutral/Starter Interlock. 111-0143
42. Battery. 70-09-015
43. Switch - Engine Oil Pressure. -
44. Starter Motor. -
ITEM NO. DESCRIPTION PART NO.
To Next Page
