HYDRAULIC CIRCUIT DIAGRAM

ITEM NO. DESCRIPTION PART NO.

Gear Pump – Triple – Cutters & Lift 950712

Relief Valve – Steering & Lift – 120 bar -

Cutter Deck Left -

Cutter Deck Centre -

Cutter Deck Right -

Cutter Motor Clockwise viewed on shaft end (QTY 3) 950714

Cutter Motor Counter Clockwise viewed on shaft end (QTY 4) 950713

Check Valve / Orifice – Motor Bypass (QTY 7) -

Steering Unit 910649W

Check Valve – Steering Shock Bypass R.H. -

Check Valve – Steering Shock Bypass L.H. -

Relief Valve – Steering Shock L.H. -

Relief Valve – Steering Shock R.H. -

Steering Cylinder – Rear Axle 70-01-195W

Spool Valve – Cutter Deck Lift LH -

Spool Valve – Cutter Deck Lift Centre -

Spool Valve – Cutter Deck Lift RH -

Hydraulic Cylinder RH Wing Cutter Deck 66-06-001W

Hydraulic Cylinder Centre Cutter Deck (QTY 2) 910109W

Hydraulic Cylinder LH Wing Cutter Deck 66-06-001W

Orifice (1.4mm) – Wing Cutter Deck, Hydraulic Cylinder 65-06-019

Cutter Drive Manifold 950715

Solenoid Valve – Centre Cutter head Drive 950611

Solenoid Valve – Left Cutter head Drive 950611

Solenoid Valve – Right Cutter head Drive 950611

Relief Valve – Centre Cutter head – 250 Bar -

Relief Valve – Left/Right Cutter head – 250 Bar -

Oil Cooler 994820

Return Filter – Bypass Check Valve – 2 Bar 924865

Hydraulic Oil Tank 994802

Suction Strainer 950608

Check Valve – Oil Cooler Bypass -

Drains From Rear Motor Wheel Motors

Motor Drains Centre Cutter head, To Port 8 Transmission Manifold

Oil Pickup To Transmission Pump

Oil From Hot Oil Shuttle
