397S, 398S & 399S PARTS LIST
PARTS LIST
2.1
2.1
397011MA260599A
1 Mainframe - 48 397039V 1 1 0
Mainframe - 53 399020V 0 0 1
2 Height Adjust Quadrant 397028 1 1 1
3 Cover - Black 397037 1 1 0
Cover - Black 399019 0 0 1
4 Engine-B+S Quantum XTL45 397007 1 1 1
5 Decal - Engine 397008 1 1 0
Decal - Engine 399008 0 0 1
6 Key Woodruff 1662 1 1 1
7 Nut-UNC 1/4” Plain 09197 2 2 2
8 Knob 397046 2 2 2
9 Washer 09475 2 2 2
10 Screw - Plastite 09765 10 10 11
11 Screw - Taptite 09596 16 16 18
12 Wheel Assembly 397021 2 2 0
Wheel Assembly 399009 0 0 2
13 Handlebar - Lower RH 397004W 1 1 1
14 Handlebar - Lower LH 307003W 1 1 1
15 Knob - M8 Handlebar 480088 2 2 2
16 Guide Rope 305127 1 1 1
17 Bolt - Handlebar 226024 2 2 2
18 Plug - Tube 300160 2 2 2
19 Cable Tie 3966 3 3 3
20 Nut 09544 1 1 2
21 Washer - Plain 09472 1 1 1
22 Guide Rope 305093 1 1 1
23 Throttle Control & OPC Assemble 397010 1 1 0
Throttle Control & OPC Assemble 480093 0 0 1
24 Screw - Detite Posi Pan 09600 2 2 2
25 Pin Pivot 340182 2 2 2
26 Lever Engine 340179 1 1 1
27 Washer - Nylon 09688 6 2 2
28 Screw - PT Pan Flange 09687 2 2 2
29 Upper Handlebar 340183W 1 1 0
Upper Handlebar 399026W 0 0 1
30 Frame - Grassbag W/A 397007W 1 1 0
Frame - Grassbag W/A 399005W 0 0 1
31 Fabric Grassbag 397006 1 1 0
Fabric Grassbag 399006 0 0 1
32 Flap - Black 397024 1 1 1
33 Spring 397025 1 1 1
DESCRIPTION PART NO. QTY.
397S 398S 399S
ITEM NO.
