PARTS LIST Continued.
2.2
397S, 398S & 399S PARTS LIST
397011MA260599A
34 Flap Attachment - Black 397026 1 1 1
35 Attachment - RH 397036 1 1 1
36 Attachment - LH 397035 1 1 1
37 Battery Holder 397034 1 1 1
38 Grip Fix 09773 2 0 0
39 Rear Attachment 397027 1 1 1
40 Bolt - Coach 09766 2 2 2
41 Attachment Plate 397018 2 2 2
42 Spring 397033 1 1 1
43 Handlebar Attachment 397017 2 2 2
44 Screw -Taptite 09546 2 2 2
45 Wheel Cover 397023 2 0 0
Cover Plate 398003 0 2 2
46 Screw - M8 x 20 09368 2 2 2
47 Height Adjustment Lever 397031 1 1 1
48 Bushing 397016 2 2 2
49 Seal Shaft 397041 2 2 2
50 Screw - Taptite 09349 3 3 3
51 Friction Disc W/A 397042W 1 1 1
52 Cutterbar 19” 480149 1 1 0
Cutterbar 21” 330032 0 0 1
53 Piece Cutterbar Distance 216008 1 1 0
Piece Cutterbar Distance 4014 0 0 1
54 Washer - Spring 09273 1 1 1
55 Screw 09116 1 1 1
56 Front Axle 397029 1 1 1
57 Height Adjustment Rod 397038 1 1 0
Height Adjustment Rod 399021 0 0 1
58 Rear Axle 397030 1 1 1
59 Grip Fix 09772 2 2 2
60 Retainer 397013 2 2 2
61 Lever Knob 397032 1 1 1
62 Spring 397012 2 2 2
63 Wheel Cover 397015 2 2 2
64 Bearing Kit 397045 4 4 2
65 Wheel Assembly - (Incl. item 64) 397014 2 2 2
66 Washer 09263 10 10 12
67 Spring 397019 2 2 2
68 Hub Cap - Black 397020 2 2 2
69 Hub Cap - Black 397022 2 2 0
Hub Cap - Black 399010 0 0 2
ITEM NO.
DESCRIPTION PART NO. QTY.
397S 398S 399S
