PARTS LIST Continued.
2.3
DESCRIPTION PART NO. QTY.
397S 398S 399S
ITEM NO.
397S, 398S & 399S PARTS LIST
397011MA260599A
70 Shaft 397040 1 0 0
71 Transmission 398001 0 1 1
72 Washer 02575 0 4 4
73 Drive Key 398004 0 2 2
74 Pin 398002 0 2 2
75 Lock Washer 398005 0 2 2
76 Gear Wheel 398007 0 2 2
77 Support Washer 398006 0 2 2
78 Lever Clutch 306094 0 1 1
79 Clip E 09767 0 2 2
80 Tension Spring 398008 0 1 0
Bracket 399022 0 0 1
81 V Belt 398011 0 1 0
V Belt 399024 0 0 1
82 Belt Pulley 398010 0 1 0
Variator Assy 399018 0 0 1
83 Pin Roll 09770 0 1 0
Pin Roll 09771 0 0 1
84 Grubscrew 09769 0 1 1
85 Bush 398012 0 1 0
Engine Spacer 399025W 0 0 1
86 Engine Belt Pulley 398009 0 1 0
Engine Belt Pulley 399012 0 0 1
87 Bracket Cable Clutch 306108 0 1 1
88 Cable Clutch 397009 0 1 1
89 Ball Bearing 399027 0 0 2
90 Knob 399016 0 0 1
91 Screw Plastite 09768 0 0 2
92 Variator Control 399017 0 0 1
93 Attachment 399013 0 0 1
94 Screw Taptite 09764 0 0 1
95 Spacer 399011 0 0 1
96 Tension Roller 399015 0 0 1
97 Tension Arm 399023 0 0 1
98 Belt Pulley 399014 0 0 1
99 Bolt 09547 0 0 1
100 Decal - Hayter 533005 1 1 1
101 Decal - Engine Stop 331046 1 1 1
102 Decal - Height of Cut 320006 1 1 1
103 Decal - Caution 219189 1 1 1
