Hayward 150 - Page 50

50 USE ONLY GENUINE REPLACEMENT PARTS
51300004201B
Table18: Service Kits
#
Item Description
150
200
250
250ASME
300
350
400
400ASME
500
500ASME
1
TOP FLUE
COVER (PLASTIC
HEADER)
FDXLJKT
1150
FDXLJKT
1200
FDXLJKT
1250
FDXLJKT
1300
FDXLJKT
1350
FDXLJKT
1400
FDXLJKT
1500
ASME (BRONZE
HEADER) *
N/A
FDXLJKT
1250A
N/A
FDXLJKT
1400A
FDXLJKT
1500A
2
FRONT ACCESS
DOOR ASSY
(PLASTIC
HEADER)
FDXLFAD
1150
FDXLFAD
1200
FDXLFAD
1250
FDXLFAD
1300
FDXLFAD
1350
FDXLFAD
1400
FDXLFAD
1500
ASME FRONT
ACCESS DOOR
ASSY (BRONZE
HEADER) *
N/A
FDXLFAD
1250A
N/A
FDXLFAD
1400A
FDXLFAD
1500A
3
REAR ACCESS
DOOR ASSY
(PLASTIC
HEADER)
FDXLRAD
1150
FDXLRAD
1200
FDXLRAD
1250
FDXLRAD
1300
FDXLRAD
1350
FDXLRAD
1400
FDXLRAD
1500
ASME REAR
ACCESS DOOR
ASSY (BRONZE
HEADER) *
N/A
FDXLRAD
1250A
N/A
FDXLRAD
1400A
FDXLRAD
1500A
4
TOP FRONT
PANEL (PLASTIC
HEADER)
FDXLTFP
1151
FDXLTFP
1201
FDXLTFP
1251
FDXLTFP
1301
FDXLTFP
1351
FDXLTFP
1401
FDXLTFP
1501
ASME TOP
FRONT PANEL
(BRONZE
HEADER) *
N/A
FDXLTFP
1251A
N/A
FDXLTFP
1401A
FDXLTFP
1501A
5
BOTH END CAPS
FDXLBEC1930
6
HEADER SIDE
TRIM PANELS
FDXLHTP1931
7
RETURN SIDE
TRIM PANELS
FDXLRTP1931
8
BASE LEG
FDXLPBL1930
9
FLUE
COLLECTOR
SIDE PANEL W/
TEMPERATURE
LIMIT
FDXLFCS1931
10
RAIN GUARD
ASSEMBLY
FDXLRGK
1151
FDXLRGK
1201
FDXLRGK
1251
FDXLRGK
1301
FDXLRGK
1351
FDXLRGK
1401
FDXLRGK
1501
11
HEAT BARRIER
PANEL
FDXLHBP
1150
FDXLHBP
1200
FDXLHBP
1250
FDXLHBP
1300
FDXLHBP
1350
FDXLHBP
1400
FDXLHBP
1500
12
EXHAUST GAS
TEMPERATURE
LIMIT (ONE-USE)
FDXLEGL1930
13
IGNITER ACCESS
COVER
FDXLIAC1930
14
CONVERSION
KIT, NA TO LP,
QUICK-CHANGE
FDXLGCK
2150NP
FDXLGCK
2200NP
FDXLGCK
2250NP
FDXLGCK
2300NP
FDXLGCK
2350NP
FDXLGCK
2400NP
FDXLGCK
1500NP
CONVERSION
KIT, LP TO NA,
QUICK -CHANGE
FDXLGCK
2150PN
FDXLGCK
2200PN
FDXLGCK
2250PN
FDXLGCK
2300PN
FDXLGCK
2350PN
FDXLGCK
2400PN
FDXLGCK
2500PN
* ASME parts for ASME models only
