Wiring Connection Diagram
WARNING - Risk of Electric Shock Before working on any electrical equipment, turn off power supply to the
equipment.
WARNING - Risk of Electric Shock. All electrical wiring MUST conform to applicable local codes, regulations,
and the National Electric Code (NEC). Hazardous voltage can cause death, shock, burn, and/or serious property
damage. To reduce the risk of electric shock, do NOT use an extension cord to connect unit to electric supply. Provide
a properly located electrical receptacle. To reduce the risk of electric shock replace damaged wiring immediately.
Locate conduit to prevent abuse from lawn mowers, hedge trimmers and other equipment. Do NOT ground to a gas
supply line.
Figure2: Wiring Diagram
To Next Page
