AED9101D
12 I3563-1.0 en
1
1 Transducer
connection
2 Interface settings
3 RS‐485 bus
termination
4 AD10x amplifier
connection
5 Terminals for
interface, supply
voltage, trigger input
and diagnostic bus
2
3
4
5
Fig. 4.1 Mechanical construction
