AED9101D
I3563-1.0 en 13
5 Mechanical installation
Conditions on site
S Protect the device from direct contact with water.
S Protect the device from moisture and weather such as
rain or snow. The protection class of the device is
IP65 (DIN EN 60529).
S Do not expose the device to direct sunlight
S Comply with the maximum permissible ambient tem-
peratures and the data on maximum humidity as
stated in the specifications.
Mounting position
The device can be mounted in any position.
Installation
Mount the device with two bolts with an outside diameter
less than 4.4mm. Remove the lid of the housing to reach
the mounting holes.
