10 Preparing the Welding Gun
Bimetallic insulation pins
Stud welding units CDi 1502 CDi 2302 CDi 3102
Material of
welding elements
Diameter of Bush
metric in mm
Welding gun parameters
1)
CA 08
Spring force
(scaling)
Lift (mm)
Spring force
(scaling)
Lift (mm)
Spring force
(scaling)
Lift (mm)
Material of workpiece: Aluminium
AlMg3 6 6 - 9 3 - 3.2 6 - 9 3 - 3.2 6 - 9 3 - 3.2
1)
to be checked by test weldings
CD ground clips (single and double style)
For welding of ground clips (single and double style) we recommend setting
the welding parameters for diameter M4.
