Audio Routing
You can use the Audio Routing page to control where your input, looper track and output audio
signals are sent. These settings are global settings (not per loop) so that you can quickly configure
HeadRush Looperboard to work best for your gear and performance settings.
To show the Audio Routing page, tap the Audio Routing icon on the Navigation Menu page.
To show the page for the inputs, tracks, or outputs, tap Input Setup, Track Setup or Output
Setup, respectively.
Input Setup
To adjust the level of an input signal, turn its Input Gain knob (1–4) on the top panel.
To adjust the panning of an input signal, tap its Pan slider and drag left or right. You can enlarge
this slider to make more detailed adjustments by double-tapping.
To select an output to directly monitor the input signal, tap the desired Output 1–4 button under
Dry Sends, or the Headphones Icon button under Monitor. Audio signal from the input will be
sent directly to the selected output(s). Use the Master and Phones knobs to adjust the output
volume level of the outputs and phones, respectively.
To stereo link your inputs if you are using a stereo audio source (e.g., drum machine,
keyboard, etc.), tap the On button for Inputs 1+2 and/or Inputs 3+4 under Stereo Link on the
right side of the touchscreen. Tap the Off button to disable stereo link.
