• Dangers caused by unexpected starting, unexpected exceeding of engine revs caused by
defect/failure of control system, relate to the defects by the handle and placing of drivers.
• Dangers caused by impossibility to stop the machine in best conditions, relate to solidity of
the handle and placing of engine shut down device.
• Dangers caused by defect of machine control system, relate to solidity of the handle, placing
of drivers and marking.
• Dangers caused by tearing (of the chain) during running.
• Dangers caused by shooting up of subjects or splashing of liquids.
UNPACKING
• Carefully remove the product from the box.
• Carefully inspect all parts. If any part is damaged or missing, contact your dealer or
authorized service center.
• Do not throw away packaging materials until you have not reviewed carefully if they did not
remain a part of the product.
• Parts of the packaging (plastic bags, paper clips, etc.) do not leave within reach of children,
could be a possible source of danger.
• Disposal must be made in accordance with the regulations in force in the country in which
the equipment was installed.
• Make sure that bags and containers of plastic material are left strewn freely in the environment
because they pollute it.
• If you have any doubt do not use the machine, but have it checked by an authorized service
center.
PACKAGE CONTENTS
1x sweeper body, 1x handles, 1x adjustment rider for brush direction, 1x set of fasteners, 1x
instruction manual
Standard accessories are subject to change without notice.
This product requires assembly. The device must be assembled correctly before use.
ASSEMBLY
The packaging materials must still be recycled or disposed of in compliance with the relevant
legislation. Sort different parts of the packaging according to material and hand it to
the appropriate collection sites. For further information contact your local administration.
Note: I
Instructions to the left and right sides start from the driving position behind the snow
thrower.
Unpack and check against the assembly diagram. In case of any missing, contact the dealer for
makeup.
1. Mount lower handles (fig. 39): As shown in (fig. 39A), use M8 x 20 (fig. 39B) and M8 x
40 (fig. 39D) hexagon bolts along with the 8.5 x 16 x 1.5 flat gaskets (fig. 39C) and SJ
gaskets (fig. 39E), two for each, to mount the lower handles onto the two mounting holes
on the left and right sides of the housing respectively.
2. Mount upper handles (fig. 40): Use M8 x 40 leaf-like bolts (fig. 40A) along with leaf-like
gaskets (fig. 40C) and flange nuts (fig. 40D), two for each, to install the operating handle
