HELI CPD15 Service Manual

11
Main Specifications（5）
Model
Unit
CPD30
CPD35
GB7Li
GB7Li
Rated capacity
kg
3000
3500
Load center
mm
500
Lifting height
mm
3000
Free lifting height
mm
145
150
Mast tilt angle (fwd/bwd) (α/β)
deg.
6/10
Fork size (T×W× L4)
mm
45×125×1070
50×125×1070
Wheelbase L1
mm
1715
Tread (front) W3
mm
1000
Tread (rear) W2
mm
990
Overall length (without forks) L’
mm
2525
2550
Overall width W1
mm
1245
Overall height (mast/overhead guard)
(H1/H4)
mm
2075/2215
2180/2215
Seat height
mm
1165
Under-clearance (H5/H6)
mm
135（at mast）/145（in the middle）
Min. turning radius r
mm
2240
2260
Fork adjustment range (outside)
Max/min W5
mm
1060/250
Travelling speed (loaded/unloaded)
km/h
17/18
16.5/17.5
Lifting speed (loaded/unloaded)
mm/s
340/460
325/450
Descending speed (loaded/unloaded)
mm/s
-/500
Gradeability (loaded)
%
18
15
Tyre ,front
28×9-15-14PR
28x9-15
Tyre, rear
200/50-10
Traction motor
kW
16.6 (AC)
Pump motor
kW
13.5 (AC)
Battery
V/Ah
80/400（standard）
80/404、80/500、80/542、80/600（optional）
Service weight(with/without battery)
kg
4490/4030
5100/4640

HELI CPD15 Specifications

General

Brand	HELI
Model	CPD15
Category	Trucks
Language	English
