HELI CPD15 Service Manual

91
2) “CONTACT CNTRL” setting is not
correct.
3) Main contactor driver shorted.
3,3
¤¤¤ ¤¤¤
PRECHARGE FAULT
1) Precharge circuit failure.
2) External short or leakage between
B+ and B-.
3,4
¤¤¤ ¤¤¤¤
MAIN CONT DNC
1) Main contactor coil connection
loose.
2) Main contactor did not close.
3) CONTACT CNTRL parameter not
correct.
4,1
¤¤¤¤ ¤
LOW BATTERY VOLTAGE
1) Battery voltage < LOVOLT
CUTBACK.
2) Corroded battery terminal.
3) Loose battery or controller terminal.
4,2
¤¤¤¤ ¤¤
OVER VOLTAGE
1) Battery voltage > overvoltage
shutdown limit.
2) Operation with charger attached.
4,3
¤¤¤¤ ¤¤¤
THERMAL CUTBACK
1) Temp > 85℃ or < -25℃.
2) Excessive load on pump motor.
3) Improper mounting of controller.
4) Working in extreme environment.
5) Thermistor failure.
4.8.2 INMOTION controller
Fault
code
Fault
Remedy
20
ERROR: Acceleration pedal is activated when
starts.
Release acceleration pedal
21
ERROR: Direction switch is activated when
starts.
Shift direction switch to neutral gear
22
ERROR: front and rear direction switches are
activated at the same time.
direction switch failure
23
ERROR acceleration pedal analog quality
exceeds range
Acceleration pedal fault or recalibrate
analog quality
24
ERROR: acceleration pedal analog failure
31
ERROR : CAN communication of driver failure
Check CAN bus or controller;
Or Instrument is disconnected.
32
ERROR: Low battery voltage
Charging is needed.
34
ERROR: CPU inner failure
It is suggested to change hardware test.
36
ERROR: Tilt switch is activated when starts.
Restore tilt switch.
37
ERROR: Side shift is activated when starts.
Restore side shift switch.
38
ERROR : Attachment switch is activated when
starts.
Restore attachment switch.
39
ERROR: Lifting switch is activated when
starts.
Restore lifting switch.
40
ERROR: lifting analog quantity exceeds range.
Lifting analog quantity is damaged or
recalibrate analog quality
