94
169
BMS current cutout protection
BMS cut output current and please check
battery.
171
BMS communication error
Please check CAN, controller and
battery.
4.8.3 SONGZHENG control system
Tab. 4-8 Fault code and treatment of SONGZHENG controller
No
Fault
Fault generation
condition
Fault exit condition
Troubleshooting
1
Motor phase line
Open
Motor phase line has more
than one phase not
connected;
1. Connect the phase
line;
2. Restart the key
1. Disconnect
immediately after
the contactor is
closed;
2. Fault indicating
lamp report 3-7 fault
code
2
Main contactor
coil open or
short circuit
DRV1 short circuit or
DRV1open circuit
1. Connect DRV1
coil;
2. Restart the
interlock switch
1. Main contactor
disconnected;
2. Fault indicating
lamp report 3-1 fault
code
3
Main contactor
adhesion
Main contactor adhesion
(note: enable contactor test
is required)
1. Replace the main
contactor;
2. Restart the key
1. The main
contactor is not
suction;
2. Within 2 seconds,
the fault indicator
will report the 3-8
fault code
4
Precharge fault
Precharge failure
1. Ensure the correct
connection of B+ and
B- lines;
2. Restart the key
1. The main
contactor is not
suction;
2. Within 2 seconds,
the fault indicator
will report the 1-4
fault code
5
High pedal
Close the key, in the given
direction or throttle >25%;
Neutral and throttle
output25%
1. The controller
does not output;
2. Failure indicator
light report 4-7
failure codes
6
Undervoltage
Power voltage the
configured undervoltage
value ±2V
Power
voltage >(configured
undervoltage value
+2V)±2V
1. Limit the
maximum current
output by the
controller
proportionally;
2. Failure indicator
light shall report 2-3
failure codes
7
Serious
undervoltage
Power voltage serious
undervoltage value ± 2V
(note: serious undervoltage
value = configured voltage
Power
voltage >(seriously
undervoltage
+2V)±2V
1. The controller
does not output;
2. The failure
indicator report a
