HELI CPD15 Service Manual

96
or > configured maximum
current value
configured minimum
current value and ≤
configured maximum
current value
16
High accelerator
output
The accelerator is not
connected or the output
voltage of the accelerator≥
5.5V
Properly connected
accelerator
1. Equivalent output
of accelerator is 0;
2.The failure
indicator light report
4—1 fault code
17
High brake
output
The brake is not connected
or its output ≥ 5.5V
(note: this fault is only
detected when the brake
pedal is enabled)
Connect the brakes
properly
1. Equivalent output
of throttle is full
brake value;
2.The failure
indicator light report
4—3 fault code
18
Accelerator
overcurrent
Too much current at the
lower end of the accelerator
or brake (100ma)
Connect accelerator or
brake properly
1. Throttle
equivalent output is
0;
2. Brake equivalent
output full brake
value;
3.The failure
indicator light report
4—5 fault code
19
Write EEPROM
failure
1. Unable to write correct
data to EEPROM;
2. The written data is not in
the specified range
1. Ensure hardware
connect properly
2. Write the correct
data;
3．Restart the key
1. The controller
does not output;
2.The failure
indicator light report
4—6 fault code
20
Read EEPROM
failure
1. Unable to read correct
data from EEPROM;
2. The data read out is not
within the set range
1. Ensure correct
hardware connection;
2. Write the correct
data
1. The controller
runs according to the
default configuration
parameters.
2.The failure
indicator light report
4—8 fault code
21
Important
parameter
modification
failure
The upper computer
modified important
parameters after the
contactor was closed
Restart the key
1.The controller
does not output;
2.The failure
indicator light report
4—9 fault code
22
Controller
overflow
The phase current output
by the controller＞700A
Restart the key
1.The controller
does not output;
2.The failure
indicator light report
1—2 fault code
23
DSP
configuration
parameter error
Error configuring
parameters for DSP
Restart the key
1.The controller
does not output;
2.The failure
indicator light report
