Hercules DJ Control Inpulse 500 User Manual

3. Controller specifications
3.1. Mechanical specifications
- Dimensions: 21.3 x 11.7 x 2.2 inches / 54 x 29.6 x 5.6 cm (width
x depth x height, with feet retracted, i.e. folded in) — 21.3 x
11.7 x 3.6 inches / 54 x 29.6 x 9.1 cm (width x depth x height,
with feet extended, i.e. folded out)
- Weight: 7.1 lb / 3.2 kg
3.2. Technical specifications
USB MIDI controller, featuring:
2 DECKS
- 2 x 4 transport buttons: SHIFT / PLAY / CUE / SYNC
- 2 sets of 8 pads = 16 in total; and 2 sets of 4 mode buttons for
pads = 8 in total (HOT CUE, LOOP, SLICER, SAMPLER, MODE 5,
MODE 6, MODE 7, MODE 8)
- 2 x 3 LOOP controls: LOOP IN and LOOP OUT buttons on each deck;
1 LOOP SIZE rotary encoder on each deck with built-in push button;
Reloop (exit the loop)
- 2 x 3 mode buttons: Vinyl / Slip / Quantize
- 2 jog wheels with capacitive touch detection
- 2 pitch faders
- 2 x 2 light guides (Tempo and Phase), to help with beatmatching
MIXER
- Navigation controls:
o 1 rotary encoder with built-in push button to navigate through
the music library, and 1 backlit ring showing the energy level
of the master track
o 2 buttons to load tracks onto the decks (virtual turntables)
o 1 Assistant button, to help you select tracks to be played
o 1 Beatmatch Guide button
- Deck mixing controls:
o 2 three-band equalizers with HIGH (treble), MID (medium)
and LOW (bass) frequency knobs
o 2 deck gain knobs
o 2 deck volume faders
o 2 deck volume VU-meters, with 9 levels each
o 2 buttons to enable/disable monitoring of the decks on
headphones, and 1 button to enable/disable monitoring of the
Master output on headphones
o 1 crossfader, plus 1 switch to select between the 3 different
crossfader curves

Hercules DJ Control Inpulse 500 Specifications

General

Channels	2
Type	DJ Controller
Number of Decks	2
Crossfader	Yes
MIDI	Yes
Jog Wheels	2
Pads	8 pads per deck
Software	DJUCED
Inputs	RCA (phono/line)
Outputs	RCA (master)
USB	1 x USB Type-B
EQs	3-band
