38
0x26
Test after software reset
This parameter activates / deactivates the
.initial test of the keyboard LED's after a
software reset .
0 … No initial test after software reset
1 … initial test after software reset
Default: 0
40
0x28
Transponder load duration
(write mode)
Charging time of a transponder during the writing
process.
The default setting should not be changed.
Default: 50 … (50ms)
41
0x29
Delay time between read
cycles
Delay time between two read cycles.
A reduction of the delay increases the reading
speed .
1 .. 250 (1 ms)
Default : 10 … (10ms)
42
0x2A
CarrierIDOffset
Sets the offset of the CID (= MID) within the MID
area. The valid value range depends on the value
of the MIDArea (maximum MID range) and the
CarrierIDLength .
0 … maximum bytes of MID - 1
Default : 0
43
0x3B
CarrierIDLength
Sets the length of the CID (= MID) within the MID
area. The valid value range depends on the value
of the MIDArea (maximum MID range) and the
CarrierIDLength.
1 … maximum bytes of MID
Default : 16
44
0x2C
FixedMID
Defines the read and write behavior of the CID
length specified in SEMI E99-03.
0 ... Dynamic CID length
The length of the MID is variable. Valid
Lengths are from 1 - CID Length Bytes.
1 ... Fixed CID length
The length of the MID is at CID Length
established. A departure from this length
leads to an error message.
Default : 1
45
0x2D
MIDFormat
Defines the physical format of the MID data in the
transponder.
0 … E99 standard format left justified
Default : 0
48
0x30
External output LED
External output LED shows reading process
0 … aktivate external LED
1 … deaktivate external LED
Default : 1 (corresponds to parameter 35)
