GPIO connection (optional)
A M8 socket (4pos.) is used as connection socket for the GPIO
8. Commissioning
Operating conditions
The following requirements must be fulfilled for smooth device operation.
1. The operating temperature must be within the scope of the values specified in the technical data.
2. The device must be connected to the power supply).
2
TxD
3
RxD
4
NC
5
GND
6
NC
7
NC
8
NC
9
NC
PIN
Signal
1
+24V
2
LED out
3
GND
4
Input
