(inventory/reading) can be defined with the parameters „Read mode“ and „Read page“.
The read data is automatically sent to the host.
The result of the reading operation (successful, not successful) can be optionally output via I/O s of the
antenna port.
6.2.4 Test module
The HERMOS LF reading devices support a test mode that facilitates setting up the antenna and checking
the reading ranges during commissioning. These test mode can be activate with a push button.
If the device is in test mode (maintenance mode) three tri-colour LEDs shows the state of the test mode.
The chapter "Status LEDs" describes the behaviour in test mode.
see also chapter „push button switches“
