Packet end
The end of the packet contains an end character and a checksum consisting of 4 characters.
End character ASCII end character <CR> (hex 0x0D).
Checksum 1 High byte XOR logic of all data (packet header, data and end character).
(ASCII character "0"…"F")
Checksum 2 Low byte XOR logic of all data (packet header, data and end character).
(ASCII character "0"…"F")
Checksum 3 High byte addition of all data (packet header, data and end character).
(ASCII character "0"…"F")
Checksum 4 Low byte addition of all data (packet header, data and end character).
(ASCII character "0"…"F")
The checksum is not necessary when using the TCP/IP interface.
(No transmission) The end character is only transmitted.
