"8" LED8: red LED STATUS
"9" LED9: blue LED STATUS
"A" LEDA: green LED STATUS
The data element shows or sets the current status of one output.
The Data Element Output State includes the status of each output on the reader.
The status is displayed as an ASCII character (1 byte) in HEX format.
0 Switch off the output permanently
1 Switch on the output permanently
2 output flashes with approx. 1 Hz
3 output remains unchanged
4 output flashes with approx. 2 Hz
The number of the parameter is displayed as an ASCII character (1 byte) in HEX format.
Example: Parameter 1 "1"
Parameter 2 "2"
Parameter 15 “F“
With single-digit parameter numbers from „0“ to „F“, the actual parameter value can be decimal or
hexadecimal depending on the command and customer mode.
Example for decimal Interpretation: Value 45 „45“
Example for hexadecimal interpretation: Value 45 „2D“ (hexadecimal)
The reader ID is defined by parameter (->Parameter E).
The reader ID is displayed as an ASCII character (1 byte) in HEX format.
This feature is not required for the individual device. This code is always "0000".
