Ex manual Rev 0 - Oct 29, 2014 26
Master switch/joystick: All master switches have an automatic
reset function, are moisture resistant
and ergonomically designed
EX-protection: Type of protection - intrinsically safe “i”
▪ I M2 EEx ia I
▪ II 2G Eex ia IIB T4
▪ II 2G EEx ia IIC T4
Ambient temperature: T0 = -20ºC to +40ºC
6.4. Antenna
Type: Miniflex TNC 440-470
Marking: Marking „440 – 470“
Length: ca. 61mm
Weight: ca. 22g
Plug : TNC
Impedance: 50Ω
Material: Plastic covered coil
Plug : Brass black chromed
Mount: Brass
6.5. Receiver
Housing material: Fiberglass-based polycarbonate (PC)
Other materials available upon request
Connection: Via moisture resistant connecting plug
Protection class: IP 65
Operating voltage: 9 - 30 VDC, 48/110/220 VAC
Weight: < 7.2 kg
Current consumption: < 0.8 A own consumption
Antenna: mostly external, with moisture resistant
connection
