CP : control panel, FC : frequency converter, SB : supply board, CB : cooling board, CC : control cable, LL : lid locking, BC : braking chopper,
BR : brake resistor, MR : mains reset, EC : error cause, ES : error consequence, ER : error remedy, M : measurements, ECR : error-code reset
21/51
General Notice for FU / CCI - ERROR 61 to FU / CCI - ERROR 69
ES
• FC switches independently.
• The rotor freewheels, coasting.
• No further user operation is possible.
• Cooling continues until nominal value is attained.
ECR
• Mains switch is OFF.
• Switch mains switch to ON after 1 min.
M Also see at FC-S501 (PIN 4) and CP-X1 (PIN 13).
FU / CCI - ERROR 61
EC Error in computing section.
ER
• CC is defective.
• FC is defective.
FU / CCI - ERROR 62
EC Undervoltage. Mains voltage less than 20% as nominal voltage.
ER
• Supply voltage too low, see chapter "Short the mains choke coil".
• CC is defective.
• FC is defective.
M Also see at FC, U
DC.
FU / CCI - ERROR 63
EC Overcurrent.
ER
• Short circuit in motor.
• Motor impedance is too low.
• CC is defective.
• FC is defective.
FU / CCI - ERROR 64
EC Voltage in intermediate circuit:
> 410 V DC at 230 V
> 205 V DC at 115 V
This error normally only occurs when the drive is being braked.
ER
• BR is defective.
• CC is defective.
• FC is defective.
M Also see FC, U
DC
.
