VertX EVO V1000 User Guide, 71000-901, Rev. A.4
V100 Series Information:
Interface Address: 0-31 Interface Type: V100, V200, V300
Tamper: AC Fail: BATT Fail:
V100 Door / Reader Interface
Reader 1: Reader 2:
Door Switch 1: REX 1: Door Switch 2: REX 2
Strike Relay 1: Aux Relay 1: Strike Relay 2: Aux Relay 2:
V200 Input Monitor Interface
Input 1: Input 2: Input 3: Input 4:
Input 5: Input 6: Input 7: Input 8:
Input 9: Input 10: Input 11: Input 12:
Input 13: Input 14: Input 15: Input 16:
Relay 1: Relay 2:
V300 Output Control Interface
Relay 1: Relay 2: Relay 3: Relay 4:
Relay 5: Relay 6: Relay 7: Relay 8:
Relay 9: Relay 10: Relay 11: Relay 12:
Input 1: Input 2:
To Next Page
