1 Introduction
HID Global’s VertX EVO® open platform is flexible and scalable to permit economic and high
performance access control solutions for a wide range of applications. The VertX EVO V1000
interconnects through different sub-networks and protocols to a standard TCP/IP network with
the capability of a variety of applications.
For example, the VertX EVO Access Controllers are a cost-effective method for two-way
communication using Ethernet between a computer and a V1000. In addition, the VertX EVO
V1000 communicates through a RS-232 serial port and multi-drop RS-485 ports.
1.1 Parts List
Description
Quantity
VertX EVO units (one of the following):
V1000 (Access Controller)
Note: Each VertX EVO controller has a plastic base and is covered with a
plastic lid.
1 V1000 used with any
combination of (up to
32) interface panels.
• Lithium Battery
1
•
Mounting screws
4
• 2.2K EOL resistors
8 ea. V1000
• Quick Installation Guide
1
• Installation Wiring Diagram Example
1
Note: One or more VertX Interface panels are required when installing a VertX EVO V1000
controller.
1.2 Product Specifications
Description
Specification
Power Supply 12-24VDC
Maximum Current at 12-24VDC per Unit 1 Amp
Average Operating Current at 12VDC 210mA
Operating Temperature Range
32°-120°F (0°- 49°C)
Humidity
5% to 85% non-condensing
SD Card Contact System/Software OEM to discuss possible
usage and SD Card specifications.
USB Port Reserved for Future Use
