Page 4 of 22 July 2016
VertX EVO V2000 Installation Guide, 72000-901, Rev. A.5
1 Introduction
HID Global’s VertX EVO® open platform is flexible and scalable to permit economic and high
performance access control solutions for a wide range of applications. The VertX EVO V2000
interconnects through different sub-networks and protocols to a standard TCP/IP network with
the capability of a variety of applications.
For example, the VertX EVO V2000 Reader Interface / Access Controller is a cost-effective
method for two-way communication using Ethernet between a computer and a V2000.
1.1 Parts List
Description Quantity
VertX EVO V2000 (Reader Interface / Access Controller)
Note: Each VertX EVO V2000 has a plastic base and is covered with a plastic lid.
1 V2000
•
Lithium Battery
1
• Mounting screws
4
• 2.2K EOL resistors
8 ea. V2000
• Quick Installation Guide
1
•
Installation Wiring Diagram Example
1
1.2 Product Specifications
Description Specification
Power Supply Input 12-24VDC
Maximum Current at 12-24VDC per Unit 1 Amp
Average Operating Current at 12VDC 625mA (with two R40 iCLASS Readers)
Reader Power Output 12VDC, 250mA each
Relay Outputs 30VDC, 2Amp, resistive
Operating Temperature Range 32°-120°F (0°- 49°C)
Humidity 5% to 85% non-condensing
1.3 Cable Specifications
Cable Type Length Specification
Input Circuits* 500 feet (150 m)
2-conductor, shielded, using ALPHA 1292C (22AWG) or
Alpha 2421C (18AWG), or equivalent.
Output Circuits* 500 feet (150 m)
2-conductor, using ALPHA 1172C (22AWG) or Alpha
1897C (18AWG), or equivalent.
Wiegand
500 feet (150 m) to
reader
ALPHA 1299C, 22AWG, 9-conductor, stranded, overall
shield.
Fewer conductors needed if all control lines are not used.
Ethernet 328 feet (100 m) Cat5, Cat5E, and Cat6
Power Supply
12-24 VDC IN
----
Refer to your Power Supply Installation Guide. Not
Provided.
* Minimum wire gauge depends on cable length and current requirements.
