Ⅰ.2 Example of other application
A. Rotary table
- Prepare the motion program in the host controller.
- Enter the operating signal and operate the angle.
- After angle operation, position decision completion signal(INPOS) is sent out externally.
B. Roll feeder
- Set the feed to the work.
- Operate the position according to the feed start signal input from the press.
- By using the position decision completion signal, execute the press work.
( The position decision completion signal and feed start signal can be interlocked on the sequence.)
Rotary table
Worm gear
Reduction gear
Servo motor
Speed pattern
Process Process Process
Deceleration pattern
Pressor
Conveyor
Feed roll
Servo motor
Induction motor
Press Press
