3.2 GPIO Interface
3.2.1 Pin Definitions
The device IO interface has 11 pins. Refer to the following table for the pin definitions of GPIO
inputs and outputs:
Table 3-2 Pin Definitions
Pin No.
Signal Name
Description
Mark
1
DI1
Opto-isolated input 1
1
2
DI2
Opto-isolated input 2
2
3
DI3
Opto-isolated input 3
3
4
DI4
Opto-isolated input 4
4
5
IN_GND
Input common ground
G
6
DO1
Opto-isolated output 1
1
7
DO2
Opto-isolated output 2
2
8
DO3
Opto-isolated output 3
3
9
DO4
Opto-isolated output 4
4
10
OUT_COMMON
Output common ground
C
11
GND
Reversed
G
GPIO is controlled via serial port, and corresponds to COM2 in the default system.
3.2.2 Opto-Isolated Input
Different electrical level types correspond to different input voltage ranges. Refer to the following
table for the relation between electrical level type and voltage range.
