HikRobot VB2200 Series - 3.6 HDMI Interface

VB2200 Series Vision Box·User Manual
10
Table 3-6 RS-485 Pin Definitions
Pin No.
Definitions
B
485-
G
GND
A
485+
RS-485 corresponds to COM3 in the default system.
3.6 HDMI Interface
The device provides 2 HDMI interfaces for connecting with the monitor with max. resolution of
2560 × 1600. If there is no monitor supporting HDMI interface, you can connect to the monitor
supporting VGA via HDMI-to-VGA devices or cables.
