HikRobot VB2200 Series User Manual

VB2200 Series Vision Box·User Manual
1
Chapter 1 Overview
1.1 Introduction
Designed for the control system, the VB2200 series vision box adopts the Intel® E3845 Quad-core
SoC processor and integrates with the various interfaces in the machine vision applications, such as
Gigabit Ethernet interface, USB, I/O, etc., featuring stable performance, compact structure, fast
response, etc.
It can be widely applied to the robots, laser equipment, numerical control machine tools, package
test, etc.
1.2 Key Features
 Onboard Intel E3845 SOC, 1.91GHz CPU.
 4GB DDR3L memory with high-reliability SSD storage.
 Integrates with GPU to support the optimization of specific algorithms and greatly enhances
the image processing performance.
 3 Intel-chip Gigabit network interfaces, with the enhanced surge-protection design to ensure
the stable access by machine vision cameras.
 2 independent HDMI video outputs.
 Supports GPIO input and output.
 Supports light source switch control and brightness adjustment by light source control
interface.
 Compact structure design.
Refer to the specification for detailed parameters.
