HIKVISION DS-1600KI User Manual

14
Figure 2.9 Modifying Network Parameters
3. Enter the Admin Password you have configured.
4. Click Modify button to complete the modification.
 You can modify the port randomly within the range from 2000 to 65535.
 You don’t need to modify the parameters of IPv6 Address, IPv6 Gateway, IPv6 Prefix Length and HTTP
Port.
Resetting the Keyboard Password
Purpose:
You can reset the keyboard password by SADP.
Steps:
1. Select the checkbox before the ID of the DS-1600KI keyboard.
2. Click to enter the Reset Password interface.
Figure 2.10 Resetting the Password

HIKVISION DS-1600KI Specifications

General

Purpose	Universal
USB hub	Yes
Pointing device	No
Device interface	USB
Recommended usage	Service
Keyboard key switch	-
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	LCD
Product color	Black
Keyboard style	Straight
Form factor	Right-hand
Operating voltage	12 V
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Keyboard weight	1700 g
Keyboard dimensions (WxDxH)	404 x 180 x 163 mm
