54
Figure 4.50 Live View Interface of Video Wall
You can edit the name of the video wall as well as the row and column in Video Wall Management
interface. Refer to Chapter 4.2.4 Managing the Video Wall for details. Refer to Table 4.7 for the description of
video wall icons.
Table 4.7 Description of Video Wall Icons
Select the window division mode.
The window division modes vary with the connected devices.
Call the scene of the video wall.
Get the present status of the video wall.
Capture picture of the selected live view window, and save the picture to the
USB disk or upload it to the FTP server. You can also press the button at the
top of the joystick to capture the picture.
Record the video of the selected live view window, and save the video to the
USB disk or upload it to the FTP server.
Enable/Disable two-way audio. You can get not only the live video but also the
real-time audio.
There is a numeric panel on the right with numbers 0 to 9 and five other icons for you to enter the serial number of
the device.
