Control Panel User Manual
40
3.1.12 Control Panel IP Configuration
For control panel IP configuration, please refer to the command below.
473 192 000 000 064 #
1 2 3
6
54
{1} Control Panel IP Configuration Programming Address: 473.
{2} Unit 1
{3} Unit 2
{4} Unit 3
{5} Unit 4.
{6} End the command.
The IP address programming includes 12 digits. The 1 to 12 place indicates the
IP address of the control panel. Each unit of the IP address includes 3 digits.
You should enter 0 if the entered address is less than 3 digits for each unit for
complement. For example, you should enter 192 002 028 066 for validating
the IP address of 192.2.28.66.
Local Port Number Configuration
The programming command of local port number setting is shown below:
474 0 8 0 0 0 #
1 2
4
63 5
7
{1} The programming command address of local port number setting is:
474;
{2} Port: Ten Thousands’ Digit
{3} Port: Thousands’ Digit
{4} Port: Hundreds’ Digit
{5} Port: Tens’ Digit
{6} Port: Units’ Digit
