User Manual of Digital Video Recorder
94
7.1.4 Backing up Video Clips
Purpose:
You may also select video clips to export directly during Playback, using USB devices (USB flash drives, USB
HDDs, USB writer), or DVD-R/W.
Steps:
1. Enter Playback interface and play back the record file you want to set video clips.
Please refer to Chapter 6.1 Playing Back Record Files.
2. During playback, use buttons and in the playback toolbar to start or stop clipping record
file(s).
3. Quit Playback interface after finishing clipping and you will then be prompted to save the clips.
Note: A maximum of 30 clips can be selected for each channel.
Figure 7. 17 Interface of Playback by Time
4. Click Yes to save video clips and enter Export interface, or click No to quit and do not export video
clips.
Figure 7. 18 Video Clip Saving
5. Export.
Click and start backup.
Note: If the inserted USB device is not recognized:
• Click .
• Reconnect device.
• Check for compatibility from vendor.
