HIKVISION DS-2CD754FWD-E Installation Manual

Installation Manual of Network Camera
59
2. Use the screws to fix the base plate on the ceiling.
Figure 6-5 Fix the Base Plate
3. View the video image of the camera over the network.
4. Loosen the lens set screws.
Figure 6-6 Loosen Set Screws
5. Insert the hex key into the hole marked in the Figure 6-7 and rotate the hex key to adjust the
panning position and tilting position until getting the desired surveillance angle. Tighten the set
screws.
Loosen the lens set
screws.
