HIKVISION DS-7100 User Manual

123
User Manual of Digital Video Recorder
Figure 7. 20 USB Flash Drive Management
Click New Folder button if you want to create a new folder in the backup device.
Select a record file or folder in the backup device and press button if you want to delete it.
Select a record file in the backup device and press button to play it.
Click Format button to format the backup device.
If the inserted USB device is not recognized:


 Click the Refresh button.


 Reconnect device.


 Check for compatibility from vendor.
 Management of USB writers
Figure 7. 21 USB Writer Management
Click Erase button if you want to erase the files from a re-writable CD/DVD.
 There must be a re-writable CD/DVD when you make this operation.
 If the inserted USB writer is not recognized:


 Click the Refresh button.


 Reconnect device.


 Check for compatibility from vendor.

HIKVISION DS-7100 Specifications

General

Video Compression	H.264
Video Input	4/8/16 channels
Audio Compression	G.711
Resolution	720P
Hard Drive	SATA
Network Interface	RJ45 10M / 100M Ethernet interface
USB Interface	2 x USB 2.0
Operating Temperature	-10 °C ~ +55 °C (14 °F ~ 131 °F)
Operating Humidity	10% ~ 90%
Audio Output	1-ch RCA(Linear, 1kΩ)
