Figure 6-3 Channel-Zero
4. Check Enable Channel-Zero Encoding.
5. Congure Frame Rate, Max. Bitrate Mode, and Max. Bitrate. The higher frame rate and bitrate
sengs result in higher bandwidth requirement.
6. Click Apply.
6.1.3 User
Refer to User for details.
6.2 Network
Conguraon
6.2.1 TCP/IP
TCP/IP must be properly congured before you operate video recorder over network.
Steps
1. Go to Conguraon → Network → General → TCP/IP .
2. Congure network parameters.
Working mode
•
Mul-address Mode: The parameters of the two NIC cards can be congured
independently. You can select LAN1 or LAN2 in the NIC type eld for parameter sengs.
You can select one NIC card as default route. And then the system is connecng with the
extranet and the data will be forwarded through the default route.
• Net-fault Tolerance Mode: The two NIC cards use the same IP address, and you can select
the Main NIC to LAN1 or LAN2. By this way, in case of one NIC card failure, the video
recorder will
automacally enable the other standby NIC card so as to ensure the normal
running of the whole system.
• Load Balance Mode: By using the same IP address and two NIC cards share the load of the
total bandwidth, which enables the system to provide two Gigabit network capacity
