6.3 Camera Management
6.3.1 Congure Signal Input
For certain models of Digital Video Recorder (DVR), you can congure the analog and IP signal
input types.
Steps
1. Go to
Conguraon → Camera → Analog .
2. Select signal input type as HD/CVBS or IP.
HD/CVBS
Four types of analog signal inputs including Turbo HD, AHD, HDCVI, and CVBS can be
connected randomly for the channel.
IP
Network camera can be connected for the channel.
3. Click Advanced
Sengs to set parameters as your desire.
Enhanced IPC Mode
If the
opon is checked, the maximum number of IP channel will increase. But it will make
smart events unavailable in analog camera.
Enhanced VCA Mode
If the opon is checked, it will maximize the number of line crossing detecon and intrusion
detecon in analog channel.
4MP Lite Mode
If the opon is checked, image of 4 MP or below resoluon can be encoded in full frame rate.
1080P Lite Mode
If the opon is checked, signal of1080p resoluon is available for the analog channels.
4. Click Apply. You can view the maximum network camera accessible number in Max. IP Camera
Number.
6.3.2 Network Camera
Acvate Network Camera
Only acvated network cameras can be added.
Before You Start
Ensure your network camera is on the same network segment with your video recorder.
