Figure 6-18 Face Detecon
2. Select Camera to congure.
3. Check Save VCA Picture to save the captured pictures of VCA detecon.
4. Check Enable Face Detecon.
5. Adjust Sensivity. Sensivity: Range [1-100]. The higher the value is, the more easily the
defocus image can trigger the alarm.
6. Set the arming schedule.
7. Set the linkage
acons.
8. Click Apply.
Intrusion
Detecon
Intrusion detecon funcon detects people, vehicles, or objects that enter and loiter in a pre-
dened virtual region.
Steps
1. Go to
Conguraon → Event → Smart Event → Intrusion .
2. Select Camera to congure.
3. Check Enable Intrusion Detecon.
4. Check Save VCA Picture to save the captured pictures of VCA
detecon.
5. Set the detecon rules and detecon areas.
1) Select Virtual Plane. Up to 4 arming areas are selectable.
2) Adjust Threshold and
Sensivity.
• Sensivity: The size of the object that can trigger the alarm. The higher the value is, the
more easily the detecon alarm will be triggered. Its range is [1-100].
• Threshold: Range [1s-10s], the threshold for the
me of the object loitering in the region.
When the duraon of the object in the dened detecon area is longer than the set me,
the alarm will be triggered.
3) Click Draw Area and draw a quadrilateral in the preview window by specifying four vertexes
of the
detecon region.
