4. Go to
Conguraon → System → Event → Normal Event → Alarm Output .
5. Select an alarm output item from the list. Refer to Alarm Outpuor the alarm output sengs.
Congure PTZ Linkage
Video recorder can trigger the PTZ acons (e.g., call preset/patrol/paern) when the alarm event,
or VCA detecon events occur.
Steps
1. Go to Linkage
Acon interface of the alarm input or VCA detecon.
2. Select PTZ Linkage.
3. Select the camera to perform the PTZ acons.
4. Select the preset/patrol/paern No. to call when the alarm events occur.
Figure 6-21 PTZ Linkage
Note
You can set one PTZ type only for the linkage acon each me.
Digital Video Recorder User Manual
68
